Component Task Reference

Related Information
"Component Service Categories" on page 57
■
"Internal Component Locations" on page 17
■
"Motherboard Component Locations" on page 21
■
"I/O Component Locations" on page 22
■
"Power Distribution and Fan Module Component Locations" on page 24
■
Component Task Reference
This table lists the names of serviceable components. This table also lists the Oracle ILOM
target and the task location for each component. Components not present on the 1-processor
server are marked with an asterisk (*).
Component
Battery
DIMMs
Drive backplane
Drives
DVD drive
Fan board
Fan modules
28 SPARC T5-2 Server Service Manual • February 2017
Oracle ILOM Target
/SYS/MB/BAT
/SYS/MB/CMn/CMP/MRn/BOBn/CHn/D0
/SYS/SASBP
/SYS/SASBP/HDD0 (bottom)
/SYS/SASBP/HDD1
/SYS/SASBP/HDD2
/SYS/SASBP/HDD3
/SYS/SASBP/HDD4
/SYS/SASBP/HDD5 (top)
/SYS/SASBP/DVD
/SYS/FANBD
As viewed from front of server:
/SYS/FANBD/F0 (left front)
/SYS/FANBD/F1 (center front)
/SYS/FANBD/F2 (right front)
/SYS/FANBD/F3 (left rear)
Links
"Servicing the Battery" on page 117
"Servicing Memory Risers and
DIMMs" on page 97
"Servicing the Drive
Backplane" on page 157
"Servicing Drives" on page 69
"Servicing the DVD
Drive" on page 113
"Servicing the Fan
Board" on page 135
"Servicing Fan
Modules" on page 81
