Memory Riser and DIMM FRU Names

Memory Riser Label
CM0/MR0
(Farthest from power
supplies)
CM0/MR1
CM0/MR2
CM0/MR3
CM1/MR0
(Not on the 1-processor
server.)
CM1/MR1
(Not on the 1-processor
server.)
98 SPARC T5-2 Server Service Manual • February 2017
Memory Riser or DIMM FRU Name
/SYS/MB/CM0/CMP/MR0 (riser)
/SYS/MB/CM0/CMP/MR0/BOB0/CH0/D0
/SYS/MB/CM0/CMP/MR0/BOB0/CH1/D0
/SYS/MB/CM0/CMP/MR0/BOB1/CH0/D0
/SYS/MB/CM0/CMP/MR0/BOB1/CH1/D0
/SYS/MB/CM0/CMP/MR1 (riser)
/SYS/MB/CM0/CMP/MR1/BOB0/CH0/D0
/SYS/MB/CM0/CMP/MR1/BOB0/CH1/D0
/SYS/MB/CM0/CMP/MR1/BOB1/CH0/D0
/SYS/MB/CM0/CMP/MR1/BOB1/CH1/D0
/SYS/MB/CM0/CMP/MR2 (riser)
/SYS/MB/CM0/CMP/MR2/BOB0/CH0/D0
/SYS/MB/CM0/CMP/MR2/BOB0/CH1/D0
/SYS/MB/CM0/CMP/MR2/BOB1/CH0/D0
/SYS/MB/CM0/CMP/MR2/BOB1/CH1/D0
/SYS/MB/CM0/CMP/MR3 (riser)
/SYS/MB/CM0/CMP/MR3/BOB0/CH0/D0
/SYS/MB/CM0/CMP/MR3/BOB0/CH1/D0
/SYS/MB/CM0/CMP/MR3/BOB1/CH0/D0
/SYS/MB/CM0/CMP/MR3/BOB1/CH1/D0
/SYS/MB/CM1/CMP/MR0 (riser)
/SYS/MB/CM1/CMP/MR0/BOB0/CH0/D0
/SYS/MB/CM1/CMP/MR0/BOB0/CH1/D0
/SYS/MB/CM1/CMP/MR0/BOB1/CH0/D0
/SYS/MB/CM1/CMP/MR0/BOB1/CH1/D0
/SYS/MB/CM1/CMP/MR1 (riser)
/SYS/MB/CM1/CMP/MR1/BOB0/CH0/D0
/SYS/MB/CM1/CMP/MR1/BOB0/CH1/D0
/SYS/MB/CM1/CMP/MR1/BOB1/CH0/D0
Ejector Slot Body
Color Color
Black Black
Black White
White Black
White White
Black Black
Black White
White Black
White White
Black Black
Black White
White Black
White White
Black Black
Black White
White Black
White White
Black Black
Black White
White Black
White White
Black Black
Black White
White Black
