Oracle SPARC T5-2 Service Manual page 29

Component
Front control panel light pipe
assembly
Memory risers
Motherboard
PCIe card (in slot 1)
Power supplies
PS backplane and cover
SP
Related Information
"Component Service Categories" on page 57
■
"Internal Component Locations" on page 17
■
"Motherboard Component Locations" on page 21
■
Oracle ILOM Target
/SYS/FANBD/F4 (center rear)
/SYS/FANBD/F5 (right rear)
N/A
/SYS/MB/CM0/CMP/MR0
/SYS/MB/CM0/CMP/MR1
/SYS/MB/CM0/CMP/MR2
/SYS/MB/CM0/CMP/MR3
/SYS/MB/CM1/CMP/MR0*
/SYS/MB/CM1/CMP/MR1*
/SYS/MB/CM1/CMP/MR2*
/SYS/MB/CM1/CMP/MR3*
/SYS/MB
/SYS/MB/PCIE1
/SYS/MB/PCIE2
/SYS/MB/PCIE3
/SYS/MB/PCIE4
/SYS/MB/PCIE5
/SYS/MB/PCIE6
/SYS/MB/PCIE7
/SYS/MB/PCIE8
/SYS/PS0 (outer)
/SYS/PS1 (inner)
/SYS/PDB
/SYS/MB/SP
Component Task Reference
Links
"Servicing the Drive
Backplane" on page 157
"Servicing Memory Risers and
DIMMs" on page 97
"Servicing the
Motherboard" on page 141
"Servicing PCIe
Cards" on page 121
"Servicing Power
Supplies" on page 89
"Servicing the PS
Backplane" on page 163
"Servicing the SP" on page 129
Identifying Components 29
