Remove the Fan Board
See
Remove all fan modules.
2.
See
"Remove a Fan Module" on page
3.
Remove all memory risers.
See
"Remove a Memory Riser and DIMM" on page
Disconnect any cables plugged into the USB or video connectors on the front of
4.
the server.
5.
Remove the fan board.
a.
Loosen the three captive screws connecting the front memory riser guide to
the motherboard (panel 1).
136
SPARC T5-2 Server Service Manual • February 2017
"Remove the Top Cover" on page
67.
83.
103.
