Remove the SP

Remove the SP
Caution -
the motherboard assembly. You must disconnect the power cables from the server before
performing these procedures.
Caution -
sensitivity can cause the component to fail. To avoid damage, ensure that you follow antistatic
practices as described in
Replacing the SP is a cold-service procedure that must be performed by qualified service
personnel. The server must be completely powered down before performing this procedure.
See "Component Service Categories" on page 57
service procedures.
The amber SP OK/Fault LED on the front panel will be lit when an SP fault is detected.
Before You Begin
If possible, back up the Oracle ILOM configuration before removing the SP.
1.
After you replace the SP, restoring the SP configuration will be easier if you previously
saved the configuration using the Oracle ILOM backup utility. Refer to the Oracle ILOM
documentation for instructions on backing up and restoring the Oracle ILOM configuration.
To retain the same version of the system firmware with the new SP, note the current version
before removing the SP.
Prepare for servicing.
2.
a. Attach an antistatic wrist strap.
Power off the server and unplug power cords from the power supplies.
b.
See
c. Remove the server from the rack.
See
d. Remove the top cover.
See
3. Locate the SP.
130 SPARC T5-2 Server Service Manual • February 2017
Ensure that all power is removed from the server before removing or installing
These procedures require that you handle components that are sensitive to ESD. This
"ESD Measures" on page
"Removing Power From the Server" on page
"Remove the Server From the Rack" on page
"Remove the Top Cover" on page
54.
for more information about this category of
58.
66.
67.
