Servicing The Sp Card; Remove The Sp Card - Oracle Netra SPARC T4-1B Service Manual

Servicing the SP Card

The server module has an SP card with firmware that provides Oracle ILOM.
"Remove the SP Card" on page 97
■
"Install the SP Card" on page 98
■
Related Information
"Detecting and Managing Faults" on page 5
■
"Preparing for Service" on page 51
■

▼ Remove the SP Card

1. If possible, save the configuration information for the SP.
Refer to the related procedures using Oracle ILOM in the SPARC and Netra SPARC
T4 Series Servers Administration Guide.
2. Prepare for service.
See "Preparing for Service" on page
3. If a REM is installed in the server module, remove the REM.
See "Remove a REM" on page
4. Push down on the tab to eject the SP card (panel 1).
51.
89.
97
