INSTALLATION AND OPERATION MANUAL

LED Indicators

This Switch is equipped with Unit LEDs to enable you to determine the status of the Switch, as well
as Port LEDs to display what is happening in all your connections. They are as follows:
Unit LEDs
LED
POWER
(Green)
POST
(Green)
ALARM
(Red)
LNK/ACT (Dual Color)
(for 1~20th Fiber ports)
LNK (Green)
(for 21~24th Fiber ports)
ACT (Green)
(for 21~24th Fiber ports)
LNK/ACT (Green)
(for 21~24th Copper ports)
1000 (Green)
(for 21~24th copper ports)
TECH SUPPORT: 1.888.678.9427
Condition Status
Illuminated Power on
Off Power off or fail
Illuminated Switch is ready and running ok
Blinking Switch is booting
Off Switch is not ready or failed
Alarm for over threshold of system temperature, fan
Illuminated
speed or voltage
Off Switch is in normal condition
Green on 1000Mbps Ethernet link-up
Amber on 100Mbps Ethernet link-up
Blinking Receiving or transmitting data
Off Port disconnected or link failed
Illuminated Link-up
Off Port disconnected or link failed
Blinking Receiving or transmitting data
Illuminated Link-up
Blinking Receiving or transmitting data
Off Port disconnected or link failed
Illuminated 1000Mbps
Off 10/100Mbp
