INSTALLATION AND OPERATION MANUAL
Parameter Description
Port Select a port or a range ports you want to configure on this screen.
State Select Enable to activate the port or Disable to deactivate the port.
Speed/Duplex Select the speed and duplex mode of the port. The choices are:
• Auto
• 10 Mbps / Full Duplex
• 10 Mbps / Half Duplex
• 100 Mbps / Full Duplex
• 100 Mbps / Half Duplex
• 1000 Mbps / Full Duplex
Flow Control Select On to enable access to buffering resources for the port thus ensuring lossless
operation across network switches. Otherwise, select Off to disable it.
Apply Click Apply to take effect the settings.
Refresh Click Refresh to begin configuring this screen afresh.
Port This field displays the port number.
State This field displays whether the port is enabled or disabled.
Speed/Duplex This field displays the speed either 10M, 100M or 1000M and the duplex mode Full or Half.
Flow Control This field displays whether the port's flow control is On or Off.
Link Status This field displays the link status of the port. If the port is up, it displays the port's speed,
duplex and flow control setting. Otherwise, it displays Link Down if the port is disabled
or not connected to any device.
