INSTALLATION AND OPERATION MANUAL
Parameter Description
IP Type Selects IPv4 / IPv6 type for the profile.
Profile Name The access control profile name.
Action Selects Disables / Drop / Permits / DSCP action for the profile.
Ethernet Type Configures the ethernet type of the packets that you want to filter.
VLAN Configures the VLAN of the packets that you want to filter.
Source MAC Configures the source MAC of the packets that you want to filter.
Mask of Source MAC Configures the bitmap mask of the source MAC of the packets that you want to filter.
If the Source MAC field has been configured and this field is empty, it means the
profile will filter the one MAC configured in Source MAC field.
Destination MAC Configures the destination MAC of the packets that you want to filter.
Mask of Destination Configures the bitmap mask of the destination MAC of the packets that you want to
MAC filter.
If the Destination MAC field has been configured and this field is empty, it means the
profile will filter the one MAC configured in Destination MAC field.
DSCP Configure the DSCP for the profile.
802.1p Configures the 802.1p for the profile.
Source IP Configures the source IP of the packets that you want to filter.
Mask of Source IP Configures the bitmap mask of the source IP of the packets that you want to filter.
If the Source IP field has been configured and this field is empty, it means the profile
will filter the one IP configured in Source IP field.
Destination IP Configures the destination IP of the packets that you want to filter.
Mask of Destination Configures the bitmap mask of the destination IP of the packets that you want to filter.
IP If the Destination IP field has been configured and this field is empty, it means the
profile will filter the one IP configured in Destination IP field.
IP Protocol Configures the IP protocol type. The setting will be used for Source Application and
Destination Application.
TCP:0x06. UDP:0x11.
Source Application Configures the source UDP/TCP ports of the packets that you want to filter.
Destination Configures the destination UDP/TCP ports of the packets that you want to filter.
Application
Source Interface(s) Configures one or a rage of the source interfaces of the packets that you want to
filter.
Apply Click Apply to add/modify the settings.
Refresh Click Refresh to begin configuring this screen afresh.
