INSTALLATION AND OPERATION MANUAL
CLI Configuration
Node Command
enable show mvr
enable show mvr vlan VLANID
enable show igmp-snooping
configure mvr VLANID
configure no mvr VLANID
MVR group NAME
MVR no group NAME
MVR inactive
MVR no inactive
MVR mode
(dynamic|compatible)
MVR name STRING
MVR no name
MVR receiver-port PORTLIST This command sets the receiver port(s). Normally the source ports are
MVR no receiver-port
PORTLIST
MVR source-port PORTLIST
MVR no source-port PORTLISTThis command removes a port or range of ports from the source
MVR tagged PORTLIST
MVR no tagged PORTLIST
MVR priority-override
(disable|enable)
TECH SUPPORT: 1.888.678.9427
Description
This command displays the current MVR configurations.
This command displays the current MVR configurations of the specific
VLAN.
This command displays the current IGMP snooping configurations.
This command configures the MVR configurations for the specific
VLAN.
This command disables the MVR configurations for the specific VLAN.
This command configures a group configuration for the MVR.
This command removes the group configurations from the MVR.
This command disables the MVR settings.
This command enables the MVR settings.
This command configures the mode for the MVR.
Dynamic : Sends IGMP report to all MVR source ports in the multicast
VLAN.
Compatible : Sets the Switch not to send IGMP report.
This command configures the name for the MVR.
This command configures the default name for the MVR.
connected to the streaming client.
This command removes a port or range of ports from the receiver
port(s).
This command sets the source port(s). Normally the source ports are
connected to the streaming server.
port(s).
This command sets the tagged port(s). Same as the VLAN tagged
port.
This command removes a port or range of ports from the tagged
port(s).
This command enables/disables the multicast priority override.
CWGE24MS2
INS_CWGE24MS2_REV–
10/05/16 PAGE 86
