INSTALLATION AND OPERATION MANUAL
Note: The DHCP Server must connect to the management VLAN member ports.
The DHCP Relay in management VLAN should be enabled.
Default Settings
The default global DHCP relay state is disabled.
The default VLAN DHCP relay state is disabled for all VLANs.
The default DHCP server is 0.0.0.0
CLI Configuration
Node Command
enable show dhcp relay
configure dhcp relay (disable |
enable)
configure dhcp relay vlan VLAN_
RANGE
configure no dhcp relay vlan
VLAN_RANGE
configure dhcp helper-address
IP_ADDRESS
configure no dhcp helper-
address
Example:
CWGE24MS2#configure terminal
CWGE24MS2(config)# interface eth0
CWGE24MS2(config-if)# ip address 172.20.1.101/24
CWGE24MS2(config-if)# ip address default-gateway 172.20.1.1
CWGE24MS2(config)#dhcp relay enable
CWGE24MS2(config)# dhcp relay vlan 1
CWGE24MS2(config)# dhcp helper-address 172.20.1.1

TECH SUPPORT: 1.888.678.9427

Description
This command displays the current configurations for the DHCP relay.
This command disables/enables the DHCP relay on the switch.
This command enables the DHCP relay function on a VLAN or a range
of VLANs.
This command disables the DHCP relay function on a VLAN or a range
of VLANs.
This command configures the DHCP server's IP address.
This command removes the DHCP server's IP address.
CWGE24MS2
INS_CWGE24MS2_REV–
10/05/16 PAGE 131
