INSTALLATION AND OPERATION MANUAL
Parameter Description
State Selects Enable or Disable to enable or disable the global UDLD state.
Message Interval Configures the message interval time.
Time
Port Selects a port or a range of ports to be configured.
State Selects the port state for above selection.
Aggressive Selects enable to let the port working in Aggressive mode. Selects disable to let the
port working in Normal mode.
UDLD Port Status
State Display the current UDLD port state for the specific port.
Aggressive Display the current Aggressive state for the specific port.
Bidirectional State Display the current detection state.
Operational State Display the current operational state.
Neighbors:
Parameter
Select Port
Port
Device Name
Device ID
Port ID
Neighbor State
TECH SUPPORT: 1.888.678.9427
Description
Selects Enable or Disable to enable or disable the global UDLD state.
The local port number.
The device name of the neighbor Switch.
The device ID of the neighbor Switch.
The port number of the neighbor Switch connected to this port.
The operational state of the neighbor Switch.
CWGE24MS2
INS_CWGE24MS2_REV–
10/05/16 PAGE 199
