INSTALLATION AND OPERATION MANUAL
Web Configuration
Port Priority
Parameter Description
All Ports 802.1p Use this field to set a priority for all ports.
priority The value indicates packet priority and is added to the priority tag field of incoming
packets. The values range from 0 (lowest priority) to 7 (highest priority).
Port This field displays the number of a port.
802.1p Priority Select a priority for packets received by the port. Only packets without 802.1p priority
tagged will be applied the priority you set here.
Apply Click Apply to take effect the settings.
Refresh Click Refresh to begin configuring this screen afresh.
