Parameter Description
Global State Enables / disables the global ERPS state.
Ring ID Configures the ring ID. The Valid value is from 1 to 255.
State Enables/ disables the ring state.
Ring Name Configures the ring name.(Up to 32 characters)
Revertive Enables / disables the revertive mode.
Instance Configures the instance for the ring. The Valid value is from 0 to 30. 0-Disable means
the ERPS is running in version 1. The control VLAN of the instance should be same as
below Control VLAN.
Control VLAN Configures the Control VLAN which is the ERPS control packets domain for the ring.
Version Configures the version for the ring.
Hold-off Timer Configures the Hold-off time for the ring. The Valid value is from 0 to 10000 (ms).
WTR Timer Configures the WTR time for the ring. The Valid value is from 5 to 12 (min).
MEL Configures the Control MEL for the ring. The Valid value is from 0 to 7. The default is 7.
Guard Timer Configures the Guard time for the ring. The Valid value is from 10 to 2000 (ms).
Left Port Configures the left port and its type for the ring. The valid port type is one of Owner,
Neighbor or Normal.
Right Port Configures the right port and its type for the ring. The valid port type is one of Owner,
Neighbor or Normal.
ERPS Status
Ring ID The ring ID.
Ring Name The ring name.
State The ring state.
Revertive The ring revertive mode.
Control VLAN The ring Control VLAN.
Version The protocol version on the ring.
Holdoff Timer The Hold-off time.
WTR Timer The WTR time.
MEL The Control MEL.
Guard Timer The Guard time.
Left Port The left port.
Left Port Type The left port type.
Right Port The right port.
Right Port Type The right port type.
WTB Timer The WTB time.
Ring Status The current ring status.
Left Port Status The current left port status.
Right Port Status The current right port status.
