INSTALLATION AND OPERATION MANUAL
Parameter Description
State Select this option to enable loop guard on the Switch.
MAC Address Enter the destination MAC address the probe packets will be sent to. If the port
receives these same packets the port will be shut down.
Port Select a port on which to configure loop guard protection.
State Select Enable to use the loop guard feature on the Switch.
Loop Recovery Select Enable to reactivate the port automatically after the designated recovery time
has passed.
Recovery Time Specify the recovery time in minutes that the Switch will wait before reactivating the
port. This can be between 1 to 60 minutes.
Apply Click Apply to save your changes to the Switch.
Refresh Click Refresh to begin configuring this screen afresh.
Loop Guard Status
Port This field displays a port number.
State This field displays if the loop guard feature is enabled.
Status This field displays if the port is blocked.
Loop Recovery This field displays if the loop recovery feature is enabled.
Recovery This field displays the recovery time for the loop recovery feature.
Time (min)
