Comnet CWGE24MS2 Installation And Operation Manual page 235

INSTALLATION AND OPERATION MANUAL
Web Configuration
Parameter
Port Security Settings
Port Security
Port
State
Maximum MAC
Port Security Status
Port
State
Maximum MAC
TECH SUPPORT: 1.888.678.9427
Description
Select Enable/Disable to permit Port Security on the Switch.
Select a port number to configure.
Select Enable/Disable to permit Port Security on the port.
The maximum number of MAC addresses allowed per interface. The acceptable
range is 1 to 30.
This field displays a port number.
This field displays if Port Security is Enabled or Disabled
This field displays the maximum number of MAC addresses
CWGE24MS2
INS_CWGE24MS2_REV–
10/05/16 PAGE 235
