INSTALLATION AND OPERATION MANUAL
Management Options
This system may be managed out-of-band through the console port on the front panel or in-band by
using Telnet. The user may also choose web-based management, accessible through a Web browser.
Web-based Management Interface
After you have successfully installed the Switch, you can configure the Switch, monitor the LED
panel, and display statistics graphically using a Web browser.
SNMP-based Management
You can manage the Switch with SNMP Manager Software. The SNMP agent decodes the
incoming SNMP messages and responds to requests with MIB objects stored in the database. The
SNMP agent updates the MIB objects to generate statistics and counters.
Configuring the Switch via Console Port
Prior to accessing the switch's onboard agent via a network connection, you must first configure
by giving a valid IP address, subnet mask, and default gateway, using an out-of-band connection
or the BOOTP protocol.
After configuring the Switch's IP parameters, you can access the onboard configuration program
from anywhere within the attached network or via internet. The onboard configuration program
can be accessed by using Telnet from any computer attached to the network. It can also be
managed with any computer using a Web browser.
Access the Switch via a terminal emulator (such as Putty, HyperTerminal, Tera Term...) attached
to the console port. The console port is set at the factory with the following default COM port
properties. Configure your own terminal to match the following:
Use terminal emulation software with the following settings:
Press [ENTER] to open the login screen.
TECH SUPPORT: 1.888.678.9427
Default Settings for the Console Port
Setting
Terminal Emulation
Baud Rate
Parity
Number of Data Bits
Number of Stop Bits
Flow Control
Setting
Default Username
Default Password
Default Value
VT100
38400
None
8
1
None
Default Value
admin
admin
