EG–90
ENGINE TROUBLESHOOTING
1.
2.
3.
4.
5.
6.
7.
8.
9.
(a) Disconnect the volume air flow meter connector.
(b) Disconnect the IAC valve and PCV hoses.
(c) Loosen the air cleaner hose clamp bolt.
(d) Disconnect the four air cleaner cap clips.
(e) Disconnect the air cleaner hose from the throttle body, and
(f)
(g) Remove the three bolts and air cleaner case.

10. REMOVE CRUISE CONTROL ACTUATOR

(a) Remove the actuator cover.
(b) Disconnect the actuator connector.
(c) Remove the three bolts, and disconnect the actuator with the
11. DISCONNECT GROUND STRAP FROM BATTERY
12. REMOVE RADIATOR
– ENGINE MECHANICAL
DISCONNECT CABLE FROM NEGATIVE TERMINAL OF
BATTERY
CAUTION (w/ Airbag): Work must be started after approx.
30 seconds or longer from the time the ignition switch is
turned to the "LOCK" position and the negative (–) termi-
nal cable is disconnected from the battery.
REMOVE BATTERY AND TRAY
REMOVE HOOD
REMOVE ENGINE UNDER COVER
DRAIN ENGINE COOLANT
DRAIN ENGINE OIL
DISCONNECT ACCELERATOR
THROTTLE BODY
(A/T)
DISCONNECT THROTTLE CABLE FROM THROTTLE
BODY
REMOVE AIR CLEANER ASSEMBLY, VOLUME AIR
FLOW METER AND AIR CLEANER HOSE
remove the air cleaner cap together with the volume air flow
meter and air cleaner hose.
Remove the air filter.
bracket.
CARRIER
CABLE FROM
