Front Panel Components (Installation)
Related Information
Server Service
■
Oracle ILOM documentation
■
"Front Panel Components (Installation)" on page 12
■
"Rear Panel Components (Installation)" on page 13
■
Front Panel Components (Installation)
No. Description
1
Serial number
2
Locator LED (white)
3
Two USB 2.0 connectors
12
SPARC S7-2 Server Installation Guide • July 2016
No.
Description
10
Server Overtemp LED (amber)
11
Drive 0 (HDD/SDD)
12
Drive 1 (HDD/SDD)
