Front Panel Components (Installation)
Front Panel Components (Installation)
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
12
SPARC T7-1 Server Installation Guide • October 2015
Description
Locator button / Locator LED (white)
Service Required LED (amber)
Power LED (green)
Power button
SP Power OK button (green)
Server serial number
Drive 0
Drive 1
Drive 2 (or NVMe drive 0)
Drive 3 (or NVMe drive 1)
Drive 4 (or NVMe drive 2)
Drive 5 (or NVMe drive 3)
Drive 6
Drive 7
DVD drive (SATA)
Fan Fault LED (amber)
PS fault LED (amber)
