3–Multi-boot Agent (MBA) Driver Software
Setting Up MBA in a Client Environment
You can use the CCM utility to configure the MBA driver one adapter at a time as
described in this section. To simultaneously configure the MBA driver for multiple
adapters, use the MS-DOS-based user diagnostics application described in
"Performing Diagnostics" on page
utility, see the Comprehensive Configuration Management User's Guide.
1. Restart your system.
2. Press CTRL+S within four seconds after you are prompted to do so. A list of
adapters displays.
a.
b.
Select the adapter to configure and press ENTER. The Main Menu
displays.
Select MBA Configuration to display the MBA Configuration menu
(Figure 3-1).
Figure 3-1. MBA Configuration Menu
240. For more information about the CCM
