8–iSCSI Protocol
iSCSI Boot
4. In the MBA Configuration menu
keys to select each of following parameters.


5. Press ESC once to return to the Main menu, and a second time to exit and
save the configuration.
6. Select Exit and Save Configurations to save the VLAN for iSCSI boot
configuration
Configuration. Press ENTER.
Figure 8-12. Saving the iSCSI Boot VLAN Configuration
7. After all changes have been made, press CTRL+ALT+DEL to exit CCM and
to apply the changes to the adapter's running configuration.

Other iSCSI Boot Considerations

There are several other factors that should be considered when configuring a
system for iSCSI boot.
Changing the Speed and Duplex Settings in
Windows Environments
Changing the Speed & Duplex settings on the boot port using Windows Device
Manager when performing iSCSI boot through the offload path is not supported.
Booting through the NDIS path is supported. The Speed & Duplex settings can be
changed using the QCC GUI for iSCSI boot through the offload and NDIS paths.
VLAN Mode: Press ENTER to change the value to Enabled
VLAN ID: Press ENTER to open the VLAN ID dialog, type the target
VLAN ID (1–4096), and then press ENTER.
Figure 8-11. Configuring iSCSI Boot VLAN
(Figure 8-12). Otherwise, select Exit and Discard
(Figure 8-11), use the up or down arrow
94 83840-546-00 E
