8–iSCSI Protocol
iSCSI Offload on VMware Server
Similar to bnx2fc, bnx2i is a kernel mode driver used to provide a translation layer
between the VMware SCSI stack and the QLogic iSCSI firmware/hardware. Bnx2i
functions under the open-iscsi framework.
iSCSI traffic on the network may be isolated in a VLAN to segregate it from other
traffic. When this is the case, you must make the iSCSI interface on the adapter a
member of that VLAN.
To configure the VLAN using the vSphere client (GUI):
1. Click the ESXi host.
2. Click the Configuration tab.
3. Click the Networking link, and then click Properties.
4. Click the virtual switch/port groups in the Ports tab, and then click Edit.
5. Click the General tab.
6. Assign a VLAN number in VLAN ID (optional).
Figure 8-22. Assigning a VLAN Number
