11–Virtual LANs in Windows
VLAN Overview
Figure 11-1
network, the physical LAN consists of a switch, two servers, and five clients. The
LAN is logically organized into three different VLANs, each representing a
different IP subnet. The features of this network are described in
Component
VLAN #1
VLAN #2
VLAN #3
Main Server
Accounting
Server
PCs #1 and #2
PC #3
PC #4
PC #5
shows an example network that uses VLANs. In this example
Table 11-1. Example VLAN Network Topology
An IP subnet consisting of the Main Server, PC #3, and PC #5. This
subnet represents an engineering group.
Includes the Main Server, PCs #1 and #2 through shared media
segment, and PC #5. This VLAN is a software development group.
Includes the Main Server, the Accounting Server and PC #4. This
VLAN is an accounting group.
A high-use server that needs to be accessed from all VLANs and IP
subnets. The Main Server has a
IP subnets are accessed through the single physical adapter inter-
face. The server is attached to one of the switch ports, which is con-
figured for VLANs #1, #2, and #3. Both the adapter and the
connected switch port have tagging turned on. Because of the tag-
ging VLAN capabilities of both devices, the server is able to com-
municate on all three IP subnets in this network, but continues to
maintain broadcast separation between all of them.
Available to VLAN #3 only. The Accounting Server is isolated from
all traffic on VLANs #1 and #2. The switch port connected to the
server has tagging turned off.
Attached to a shared media hub that is then connected to the
switch. PCs #1 and #2 belong to VLAN #2 only, and are logically in
the same IP subnet as the Main Server and PC #5. The switch port
connected to this segment has tagging turned off.
A member of VLAN #1, PC #3 can communicate only with the Main
Server and PC #5. Tagging is not enabled on PC #3 switch port.
A member of VLAN #3, PC #4 can only communicate with the serv-
ers. Tagging is not enabled on PC #4 switch port.
A member of both VLANs #1 and #2, PC #5 has an
adapter installed. It is connected to switch port #10. Both the
adapter and the switch port are configured for VLANs #1 and #2
and have tagging enabled.
157
Description
QLogic
adapter installed. All three
Table 11-1.
