Installing Firmware From The Tftp Server On The S8300 Server - Avaya G450 Installing And Upgrading

Table 8: Sample Software and Firmware File names (continued)
Component
Media Modules
MM710 E1/T1 Media Module
MM711 Analog Port/Trunk Media Module
(version 6 or earlier)
MM711 Analog Port/Trunk Media Module
(version 7)
MM711 Analog Port/Trunk Media Module
(version 20 or later)
MM712 DCP Media Module
MM714 Analog Port/Trunk Media Module
MM716 Analog Port/Trunk Media Module
MM717 DCP Media Module
MM720 BRI Media Module
MM722 BRI Media Module

Installing firmware from the TFTP server on the S8300 Server

Instead of using a separately configured TFTP server on the LAN, you can use the TFTP server
capability of an S8300 Server to stage the firmware for upgrading the G450. To do this, you
must copy the individual firmware files to the /var/home/ftp/pub directory on the S8300 Server
using the Download Files web page on the S8300 Server. You must then copy the files to the
/tftpboot directory of the S8300 Server.
After copying the files to the /tftpboot directory, you can use the GIW or the Upgrade Tool to
install the files to the G450 or its media modules by specifying the S8300 Server's IP address as
the TFTP server containing the new firmware files.
Note:
You only have to do this if you have not upgraded the S8300 first or if you did
Note:
upgrade it first and found that the gateway files on the communication manager
CD were out of date. Otherwise, when you upgrade the S8300, the files appear in
the /tftpboot directory automatically.
Upgrading G450 firmware using the CLI via FTP/TFTP
File name Example
mm710v3.fdl
mm711v16.fdl
mm711h7v21.fdl
mm711h20v54.fdl
mm712v14.fdl
mm714v5.fdl
mm716v80.fdl
Mm717v3.fdl
mm720v1.fdl
mm722v3.fdl
2 of 2
Issue 2 June 2008 109
