EG2–48
ENGINE – ENGINE MECHANICAL
20. INSTALL PS PUMP

21. INSTALL PS PUMP PULLEY AND DRIVE BELT

22. INSTALL SPARK PLUGS
Using a 16 mm plug wrench, install the six spark
plugs.
Torque: 18 N–m (180 kgf–cm, 13 ft–lbf)
23. CONNECT HIGH–TENSION CORDS TO SPARK
PLUGS
24. CONNECT NO.2 AND NO.3 AIR HOSES TO AIR PIPE

25. INSTALL RADIATOR

(a) Install the radiator with the four bolts.
(b) Install the No.1 fan shroud with the four bolts.
(c) Install the No.2 fan shroud with the two clips.
(d) Install the radiator hoses.
(e) (A/T only)
Connect the oil cooler hoses.
(f) Connect the reservoir tank hose.
26. CONNECT CABLE TO NEGATIVE TERMINAL OF
BATTERY
27. FILL WITH ENGINE COOLANT
28. START ENGINE AND CHECK FOR LEAKS

29. RECHECK ENGINE COOLANT LEVEL
