2.4 Connecting the Printer to a Computer

Connecting the USB interface cable
Connect the prnter body and a PC wth a USB nterface cable va a USB nterface connector. The USB
nterface cable has connectors wth dfferent shapes for a PC and for the prnter. Be sure to check the shape of
each connector and approprately connect the cable.
USB Interface Connector
Right side of
the printer body
USB connector
To a PC
USB2.0
Interface cable
CAUTION
Insert the USB interface cable securely into the USB interface connector.
●
2-6
