Man Menu Sub Menu
3. Platform
4. PH Heater
5. Meda Detect
Functon descrpton
Set the temperature (°C) for the Platform Heater.
Menu 3.Platform
0045
Offline
To change the value by usng [▲▼] (up/down) keys.
Settng range: 0000 - 0099 (Default value: 0045)
Press the [ENTER] key to store the set value.
Press the [ESC] key to cancel the set value. (The mmedately precedng
set value remans as the current set value.)
If a value of 60°C or over is specified, a protection circuit works, and the
temperature does not move exceedng 60 °C.
Set the temperature (°C) for the PH Heater.
Menu 4.PH Heater
0030
Offline
To change the value by usng [▲▼] (up/down) keys.
Settng range: 0000 - 0099 (Default value: 0030)
Press the [ENTER] key to store the set value.
Press the [ESC] key to cancel the set value. (The mmedately precedng
set value remans as the current set value.)
If a value of 60°C or over is specified, a protection circuit works, and the
temperature does not move exceedng 60°C.
Enable (on) or dsable (off) the Meda Detect functon.
Menu 5.Media Detect
on
Offline
Press [▲▼] (Up/Down) keys to toggle between on and off.
(Default value: on)
on: Enabled (default settng)
off: Dsabled
Press the [ENTER] key to store the set value.
Press the [ESC] key to cancel the set value. (The mmedately precedng
set value remans as the current set value.)
When the set lever s rased and then lowered whle the settng s "on",
the followng s dsplayed on the LCD.
Menu Media Detect
Start: 0000 mm
Length: 0000 mm
Offline
Press the [ESC] key to cancel the Meda Detect functon. (In ths case, the
mmedately precedng set value remans as the current set value).
Press the [ENTER] key to start the Meda Detect functon. When the
sensor successfully completes the paper wdth detecton, the LCD
dsplays "OK", and the poston of the paper and the paper wdth are
stored. The set poston of the paper whch s loaded here (a value from
the Home Position to the position of the paper) is reflected in the set value
of the Prnt Poston after addng the set value for the "Margn" (a set value
for the margn on the paper edge). See "3.5 Detectng the paper wdth
and the poston where the paper s set" descrbed above for detals.
