5.4 Start up "GPU"
1. Double-clck the con on the desktop.
Or start up from Start → All Programs → GPU.
5.5 Explanation of functions in the Print Setup
Open [Prnt Setup].
1. Settng the EF Setup
Ths functon allows settng of the EF value.
To change the set value, the prnter should be onlne. Set the prnter onlne to allow for communcaton.
Settng range s 0.5 - 1.5.
The value can be directly inputted or can be specified by using the spin button.
GET:
Load the set value from the prnter.
SET:
Set the value on the prnter by usng a PC.
Cancel: Qut ths screen. The set value whch s beng nputted s dscarded.
K
Head 3
Head 2
Head 1
* When the applcaton s started up, all the values are shown as 1.00.
To change the input value, perform the upload operation first to display the latest setting before changing.
2. Settng the prntng colors
Check the checkbox of the colors to use for prntng.
Wthout checkng these colors, prntng s not performed.
Y
M
C
Head 3
Head 2
Head 1
(Top view)
Printhead carriage
5-5
