4.4 Functions of each menu
Menu
Man Menu
1. Ink Status
2. Heat Status
3. Cleang Tool 1. Frng
2. Jam Test
3. PH Mantenance
4. Home Post
Sub Menu
Dsplays the status of each nk cartrdge.
Menu Ink Status
Ch C M Y K
Rn _ _ _ _
Offline Al _ _ _ _
Ch: Indcates each nk cartrdge (Channel).
Rn: Indcates the pump whch s operatng.
Al:
Pressng the [Drecton] key on ths screen allows cleanng operatons
(postve pressure) for the nk cartrdge whch corresponds to each key.
See "6.4.3 Manual Cleanng" descrbed later for detals.
[ ]Key: Cyan
[ ]key: Yellow [▼]Key: Black
Dsplays the status of each heater.
Menu Heat Status
FP PF PH
Tem. 00 00 00
Offline Set. 00 00 00
FP: Front Heater and Pre Heater
PF: Plat from Heater
PH: PH Heater
Tem: Indcates the current heater temperature.
Set: Indcates the set heater temperature.
Performs an empty ejecton of nk to dscharge the nk whch becomes
thick in the Print Head Nozzle.
Pressng the [ENTER] key dsplays a "Busy" message on the LCD, and
then an empty ejecton s performed.
The "Busy" message dsappears after the empty ejecton s complete.
The number of tmes the empty ejecton functon s performed can be
changed on the Sub Menu "Frng Vol." of the Menu "Prnt Para".
To ncrease the number of tmes of the empty ejecton functon s
performed, ncrease the set value for the "Frng Vol."
See "6.3 Firing (empty ejection)" described later for details about firing
operatons.
Press the [Enter] key to perform the Test Prnt.
See "6.2 Jam Test" descrbed later for detals about the Jam Test.
Press the [Enter] key to move the P/H carrage to the PH Mantenance
Poston.
Press the [Enter] key to move the P/H carrage to the Home Poston.
Functon descrpton
Menu Ink Status
Ch C M Y K
Rn _ _ _ _
Offline Al _ _ _ _
Indcates the Channel for whch an alarm s actvatng.
When nk cartrdges are not set or when nk cartrdges are empty, an alarm
s actvated, and the Channel s dsplayed.
After the relevant nk cartrdge s replaced, the alarm s automatcally
deactvated, and the prnter returns to ts normal operaton.
[▲]Key: Magenta
Menu Heat Status
FP PF PH
Tem. 00 00 00
Offline Set. 00 00 00
4-4
