GRAPHTEC JS500 User Manual page 77

2. Make an adjustment of the space between cyan color and other colors (Horizontal Space).
1) Open the file "3_H_Space_Color_12HEAD.group" and start printing.
* For 8-head model printers, open "2_H_Space_Color_8HEAD.group".
-20 -18 -16 -14 -12 -10 -8 -6 -4 -2
-20 -18 -16 -14 -12 -10 -8 -6 -4 -2
-20 -18 -16 -14 -12 -10 -8 -6 -4 -2
2) Check the results of prntng, select where the prnted lnes are algned most closely as one lne, and
nput the compensaton value ndcated wth the lne.
* If an adjusted value has already been nputted, add the above value to the exstng value.
3) Perform printing again to confirm that the printing of lines of each color is aligned most closely as one
lne where ±0 s ndcated.
If the adjusted condton s not what s ntended, repeat steps from 1 to 3.
3. Make an adjustment of the Vertcal Space.
1) Open the file "4_V_Space_12HEAD.group" and start printing.
* For 8-head model printers, open "3_V_Space_8HEAD.group".
-5
-4
-3
-2
-1
0
+1
+2
+3
+4
+5
-5
-4
-3
-2
-1
0
+1
+2
+3
+4
+5
-5
-4
-3
-2
-1
0
+1
+2
+3
+4
+5
2) Check the result of prntng, and nput the compensaton value ndcated wth the lne.
3) Perform printing again to confirm that the printing of lines of each color is aligned most closely as one
lne where ±0 s ndcated.
If the adjusted condton s not what s ntended, repeat steps from 1 to 3.
0 +2 +4 +6 +8 +10 +12 +14 +16 +18 +20
0 +2 +4 +6 +8 +10 +12 +14 +16 +18 +20
0 +2 +4 +6 +8 +10 +12 +14 +16 +18 +20
-5
-4
-3
-2
-1
0
+1
+2
+3
+4
+5
-5
-4
-3
-2
-1
0
+1
+2
+3
+4
+5
-5
-4
-3
-2
-1
0
+1
+2
+3
+4
+5
5-9
Printing with Head-3
Printing with Head-2
Printing with Head-1
Printing with Head-3
Printing with Head-2
Printing with Head-1
