Chapter 7 Setting the heater
7.1 Outline
The heater warms up the media and the printheads to an appropriate temperature to maximize the printing
qualty.
The current setting can be confirmed by displaying the Heat Status from the LCD Control Panel.
Set the value dependng on the meda and the usage envronment.
(1) Select [2.Heat Status] from the man menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
(2) The set temperature and the current temperature are dsplayed on the LCD.
Menu
Offline
1.Ink Status +
2.Heat Status +
3.CleaningTool +
4.Print Para +
Heat Status
FP PF PH
Tem. 00 00 00
Set. 00 00 00
7-1
