1.2 Parts Names and Functions

Front View
8
10
9
12
No. Name
1 Top cover
2 Front cover
3 Front cover clear
4 Rear cover
5 Rght upper cover
6 Rght bottom cover
7 Sde cover (Rght)
8 Left upper cover
9 Left bottom cover
10 Sde cover (Left)
11 Man cleanng poston
12 Prnt Head Mantenance poston
4 3 2 1
The upper front cover.
The front cover.
The front clear cover.
The upper rear cover.
The upper rght cover.
The cover at the cleanng poston.
The rght sde cover.
The upper left cover.
The cover for the mantenance staton.
The sde cover.
The Home Poston of prntheads.
Cappng and Auto Cleanng of the prntheads are performed at ths poston.
At the ntal setup: Installaton of the prntheads and ntal pourng of nk are
During normal use: Recovery procedures for nozzles of the printheads are
1-3
Functons
performed at ths poston.
performed n case that mantenance s requred due to
faded prnt.
5
6
7
11
