How to adjust the Media Take-up Sensor
CHECKPOINT ● The Media Take-up Sensor may not work depending on the indoor conditions where it
is used. In such a case, make an adjustment by using the following method.
Set the Meda Take-up System Swtch to the "=" sde (automatc takng-up paper), adjust the senstvty
by turnng the adjustment knob so that the sensor correctly detects the feedng of the paper whch allows
automatc takng-up the paper.
The sensor LED lghts as ndcated below:
Sensor LED lights red/green -
The sensor is detecting.
1. Feed the paper to the poston of the Meda Take-up Sensor.
Pulling out the paper media
(1) Select [4.Prnt Para] from the man menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
Media Take-up Sensor
1.Ink Status +
2.Heat Status +
3.CleaningTool +
4.Print Para +
3-12
Media Take-up Sensor
Adjustment knob
Sensor LED lights green -
It is operating normally.
Slack the paper off
Sensor LED
