7.4 P/H Heater

7.4.1 Explanation of functions
The P/H Heater mantans a constant temperature of the nk n the prntheads to mprove the stablty of
ejectons of nk.
7.4.2 Setting method
Set the value from the LCD Control Panel.
(1) Select [5. Applcaton] from the man menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
(2) Select [4.PH Heater] from the sub menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
(3) To change the value by usng [▲▼] (up/down) keys.
Menu
Offline
Settng range: 0000 - 0099 (Default value: 0030)
(4) [Press the [ENTER] key to store the set value.
Press the [ESC] key to cancel the set value. (The mmedately precedng set value s enabled as the
current set value).
The approprate settng depends on the ambent temperature and types of nk, however, a settng of around
35°C s recommended.
If the temperature is too high, ink may drip off and wetness around the nozzles may deteriorate the printing
condton.
If the temperature s too low, the supply of nk may become unstable.
2.Heat Status +
3.CleaningTool +
4.Print Para +
5.Application +
1.Time to LPM
2.FH and Pre
3.Platform
4.PH Heater
4.PH Heater
0030
7-4
