GRAPHTEC JS500 User Manual page 66

Man Menu
6. Mantenance 1. Movng Test
2. Lcense
3. About
4. Default Set.
7. Engnner 1. PH Mant. Post.
2. Prnter Wdth
3. Parkng Post.
4. Y Test Speed
5. X Test Speed
Sub Menu
Performs a movng test of the PH carrage and the Meda Feed Roller.
Menu
Offline
Press the [ENTER] key to start the test.
The P/H carrage moves from rght and left, and the Meda Feed s
performed for each rotaton. In ths case, the P/H does not perform
ejecton.
The numerc value on the LCD ndcates the number of rotatons of the
P/H carrage's movement.
Press the [ESC] key to qut the test.
Unused
Dsplays the Verson nformaton of ths prnter.
Reset the settng to default values (factory default settng).
Pressng the [FUNC] + [ENTER] keys smultaneously dsplays a "Busy"
message on the LCD, and the reset operaton s performed.
CAUTION
Please be careful to perform this operation because all the set
values are reset to the factory default setting. It is recommended
that the user take note of the current set values before executing
the reset operation.
Dsplay the PH Mantenance settng.
* This setting is configured as the factory default setting and cannot be
changed.
Dsplays the settng of the maxmum prntng wdth for ths prnter.
* This setting is configured as the factory default setting and cannot be
changed.
Dsplay the Parkng Post. settng.
* This setting is configured as the factory default setting and cannot be
changed.
* This setting is configured as the factory default setting and cannot be
changed.
* This setting is configured as the factory default setting and cannot be
changed.
4-10
Functon descrpton
1.Moving Test
0000
