6.5 Cleaning during printing
When any printhead has smaller frequency of ejections of ink, the ink in the nozzle is gradually fixed which
may result n defectve ejectons or non-ejecton of nk. Contnung prntng n such a condton leads to
deteroraton of prntng qualty due to occurrences of bandng.
Use the followng steps to set the "Flash Mode" and the "Frng Volume".

6.5.1 Flash Mode

Set the empty ejection mode which is performed during printing. To avoid the fixing of ink in the nozzles of the
prntheads whch have a smaller frequency of ejectons of nk, perform empty ejectons (Frng) accordng to
the set value for the prntng passes. Set an approprate value by checkng the prntng condton.
(1) Select [4.Prnt Para] from the man menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
(2) Select [6.Flash Mode] from the sub menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
(3)
To change the value, move the cursor by usng [
keys.
Menu
Offline
Settng range: 0000 - 0300 (Default value: 0001)
0001 - 0009 : Flash only
0010 - 0030 : Auto Clean
1.Ink Status +
2.Heat Status +
3.CleaningTool +
4.Print Para +
3.Print Speed -
4.Feed Speed -
5.Firing Vol. -
6.Flash Mode -
6.Flash Mode
0001
Flash only
] (left/rght) keys, and change the value by usng [▲▼] (up/down)
6-7
