3.7 Setting the Margin (the margin on the paper edge)
Set the margn (mm) between the paper edge detected by the Meda Detect functon and the prntng startng
poston. Use the followng steps to set the value.
(1) Select [5.Applcaton] from the man menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
(2) Select [6.Margn] from the sub menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
(3) To change the value, move the cursor by usng [
(up/down) keys.
Settng range: 0000 - (Default value: 0020)
Menu
Offline
(4) Press the [ENTER] key to store the set value.
Press the [ESC] key to cancel the set value. (In ths case, the mmedately precedng set value remans as
the current set value)
(5) To reflect the set Margin value to the printing starting position (Print Position), be sure to execute the Media
Detect (paper width detection) function again after setting the margin. The set Margin value is reflected in
the Prnt Poston only after Meda Detect s executed.
2.Heat Status +
3.CleaningTool +
4.Print Para +
5.Application +
3.FH/Pre Heater
4.PH Heater
5.Media Detect
6.Margin
6.Margin
0020
] (left/rght) keys, and change the value by usng [▲▼]
3-20
