Rear Of The PrNter Body (RGht) - GRAPHTEC JS500 User Manual

Rear of the printer body
2
No. Name
1 Rubber Roller
2
Meda Tenson Bar
Rear of the printer body (right)
1
2 (Cyan, Magenta, Yellow, Black)
No. Name
1 Ink holder C, M, Y, BK
2 Ink cartrdge C, M, Y, BK
2
1
Ths part s an mportant part to stretch the meda for better prntng qualty.
Ths part s an mportant part to stretch the meda for better prntng qualty.
Ths s where nk cartrdges are nstalled. Check the C, M, Y and BK labels on
the ink cartridges, and appropriately install them in the holders specified for
each.
Four nk cartrdges, whch are Cyan, Magenta, Yellow and Black.
