Symptom
Ink s not ejected.
Prntng has blurred.
The edge of the paper
becomes drty.
Color tone of prntng s
dfferent from the orgnal.

If the Paper Becomes Jammed

Turn the power off, remove the jammed paper, and check f there s no obstacle where the carrage and the
paper go through.
Set the paper, and turn on the power agan.

Occurrence of an abnormal sound

If you feel that the sound of the prnter s dfferent from that of a normal operaton, contact the dstrbutor.
Cause
Tubes have ar nsde.
No nk n nk cartrdges.
Nozzles of the printheads are clogged up.
Settng of the GPU s not approprate.
EF value s not approprate.
Flexble prnted crcuts of the prntheads
are connected.
Settng of the temperature of the heater s
not approprate.
Paper type s not approprate.
The front sde and the back sde of paper
are faced to the wrong sde of the prnter.
Prntng densty does not match the paper
type.
The edge guard s not approprately set.
Paper s wrnkled or curled.
The platen s drty.
No nk n nk cartrdges.
Nozzles of the printheads are clogged up.
EF value s not approprate.
Flexble prnted crcuts of the prntheads
are connected.
10-3
Soluton
Remove the ar n the tubes.
(See the "Setup Manual".)
Replace the nk cartrdge wth a new one.
(See "9.1 Replacng the Ink Cartrdge" n ths
manual.)
Perform cleanng.
If cleanng does not solve the problem, wpe off
the nk on the prntheads.
(See "6.4 Prnthead Cleanng" n ths manual.)
(See "5 Software" n ths manual.)
Set an approprate EF value.
(See the "Setup Manual".)
(See the "Setup Manual".)
(See "7 Settng the heater" n ths manual.)
Use the dedcated paper for solvent nkjet
prnters.
Check the settng of the paper.
Lghten the prntng.
(See "Settng a roll paper" n ths manual.)
Set the paper after removng wrnkles and curls.
Clean the platen.
Replace the nk cartrdge wth a new one.
(See "9.1 Replacng the Ink Cartrdge" n ths
manual.)
Perform cleanng.
If cleanng does not solve the problem, wpe off
the nk on the prntheads.
(See "6.4 Prnthead Cleanng" n ths manual.)
Set an approprate EF value.
(See the "Setup Manual".)
(See the "Setup Manual".)
