7. Carefully wipe the part which has contact with the cap on the lower side of the plate which fixes the
prntheads.
Move the Prnthead Carrage to the Home Poston or to the Cappng Poston after all the work s complete.
Clean the Cleaning Roller with Ink Cleaning Solution
Use the followng steps for cleanng.
Be sure to apply nk cleanng soluton to the entre roller once every three days.
1. Move the Prnthead Carrage to the Cappng Poston.
Select [3.Cleanng Tool] from the man menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu 1.Ink Status
2.Heat Status
3.CleaningTool
Offline 4.Print Para
Select [7.Parkng] from the sub menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu 4.Home Post.
5.Clean
6.Clean(Heavy)
Offline 7.Parking
2. The Prnthead Carrage moves to the Cappng Poston and s capped.
3. Open the panel on the front lower rght sde. Openng these panels allows access to the Cleanng Roller.
4. Rotate the Cleanng Roller by usng the attached brush to apply Ink Cleanng Soluton to the entre roller.
Ink Cleaning Solution
Rotate
Cleaning roller
+
+
+
+
-
-
-
-
Injector
Brush
