Side of the printer body (left)
No. Name
1 Heater Swtch
2 Meda feedng System swtch
3 Meda take-up System swtch
4 Heater soket
5 Power soket
6 Power Swtch
Side of the printer body (right)
No. Name
1 USB nterface connector
1 2 3
4 5 6
The swtch for the Heater (Pre Heater, Front Heater, Plat form Heater).
The swtch for the meda feedng system.
The swtch for the meda take-up system.
The dedcated power supply swtch for the Heater.
The power socket on the prnter body.
The power swtch of the prnter body.
1
The connector for a USB nterface cable.
1-7
Functons
Functons
