4. Make an adjustment of the bdrectonal prntng.
1) Open the file "5_BiD_123_12HEAD.group".
* For 8-head model printers, open "4_BiD_12_8HEAD.group".
Printing in the
forward direction
-20 -18 -16 -14 -12 -10 -8 -6 -4 -2
Printing in the
backward direction
-20 -18 -16 -14 -12 -10 -8 -6 -4 -2
-20 -18 -16 -14 -12 -10 -8 -6 -4 -2
2) Check the B Drecton checkbox to actvate the bdrectonal prntng.
3) Perform printing so as the printing with the first pass and the second pass is almost overlapped.
To make the meda feed amount close to "0", adjust the value for the Feed Compensaton.
* As a rough ndcaton, a settng around "-15000" (Around "-10000" n the case of 8-head model
prnters) makes the meda feed amount close to "0". Make an adjustment of the value where
approprate.
4) Print the file "5_BiD_123_12HEAD.group" ("4_BiD_12_8HEAD.group").
5) Check the results of prntng, select where the prnted lnes are algned most closely as one lne, and
nput the compensaton value ndcated wth the lne.
6) Feed the paper manually more than around 6 cm.
See "3.6 Set the Prnt Poston" for detals.
7) Perform printing again to confirm that the printing of lines of each color is aligned in one line where ±0 is
ndcated.
If the adjusted condton s not what s ntended, repeat steps from 1 to 7.
0 +2 +4 +6 +8 +10 +12 +14 +16 +18 +20
0 +2 +4 +6 +8 +10 +12 +14 +16 +18 +20
0 +2 +4 +6 +8 +10 +12 +14 +16 +18 +20
5-10
Printing with Head-3
Printing with Head-2
Printing with Head-1
Printing with Head-3
Printing with Head-2
Printing with Head-1
