Maintenance station
3
No. Name
1 Cleanng roller
2 Cappng unt
3
Meda Set Lever

Front cover

No. Name
1 Pnch roller
2 Prntng Platform
3
Meda gude
4 (Y-encoder)
1
2
Ths roller cleans the prntheads. The cleanng roller s a replaceable tem.
Please replace t wth a new one f t becomes drty.
These parts are used for cappng the prntheads.
Ths lever s used to set or remove meda.
1 4
3 2
These parts are mportant parts to forward paper. They retan the paper n
place.
The prntheads pass on ths part durng prntng.
This part prevents the paper edges from floating.
Ths part s an mportant part to move the Prnthead Carrage.
