9.4 Periodical maintenance

Daily maintenance
To mantan stable performance of the prnter, perform the followng everyday.
Moistening the sponge in the cap with Ink Cleaning Solution
The carrage s capped n the Cappng Poston when the prnter s n the standby mode. To avod dryng of the
printhead nozzles, the inside of the cap is required to be saturated with an appropriate amount of moisture
from Ink Cleanng Soluton. Use the followng steps to pour Ink Cleanng Soluton nto the cap.
1. Move the Prnthead Carrage to the PH Mantenance Poston.
Select [3.Cleanng Tool] from the man menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key.
Menu
Offline
Select [3.PH Mantenance] from the sub menu by usng [▲▼] (Up/Down) keys, and press the [ENTER] key
Menu
Offline
2. The Prnthead Carrage s moved to the PH Mantenance Poston.
3. Open the panel on the front lower rght sde. Openng the panel allows access to the Cappng Unt.
4. Pour Ink Cleanng Soluton nto the cap.
Keep on pouring it until the fluid level reaches the position of the metal plate in the cap.
Spoid
Ink Cleaning Solution
5. Return the Prnthead Carrage to the Cappng Poston.
(Select [7.Parkng] from the sub menu.)
1.Ink Status +
2.Heat Status +
3.CleaningTool +
4.Print Para +
1.Firing -
2.Jam Test -
3.PH Maintenance -
4.Home Post. -
Metal plate
Pour Ink Cleaning Solution
until the fluid level reaches
the position of the metal plate
Cap
9-5
