7.2 Approved Media and Ribbon

Media (and ribbon for thermal transfer) is an important determinant in the throughput, quality, and
performance of the printed product. The following overview is an introduction to the different types
of material that can be used in the printer. For complete information and advice regarding a
specific application, consult a qualified media specialist or a Datamax-O'Neil Media Representative.
Also available is an informative white paper, "A Brief Introduction to Media," which can be found on
our website at www.datamax-oneil.com
Direct Thermal
Consider three important factors when selecting direct thermal stock:
The abrasiveness of the material that covers the thermal reactive layer of the paper;
•
The amount of heat required to start the chemical reaction; and,
•
The ability of the media to control that chemical reaction.
•
Thermal Transfer
Consider three important factors when selecting thermal transfer media and ribbon combinations:
Label top coating and ribbon combinations may affect image quality;
•
Ribbon back coating can provide printhead protection and, depending upon the formula, help
•
reduce static buildup; and,
The ribbon width, when slightly wider than the media, can also guard the printhead against
•
media abrasion.
Media and Ribbon Selection
To achieve optimum print quality and maximum printhead life, we specify the use of Datamax-
O'Neil brand media. These supplies are specially formulated for use in our printers; use of non-
Datamax-O'Neil supplies may affect the print quality, performance, and life of the printer or its
components. For a current list of approved media, please contact a Media Representative at (407)
523-5650.
Suggested applications are listed below:
Direct Thermal Media
Datamax-O'Neil DTL-HSM
Datamax-O'Neil DTL-HSH
122
Media and Ribbon Overview
Print
Speed*
10 – 12**
10 – 12**
Print Image
Energy Durability
Medium
Medium
Low
Low
A-Class
