Step Action
Lower and latch the Head
Lift Lever.
Using the UP or the DOWN
Key, set the Gain Number
I to 00 and then press
ENTER.
Record this reading as a
TOF Value for Gain
Number 00 in the table.
Gain Number
Step Action
Use the keys to increment
the Gain Number by one
and then press the ENTER
J
Key. Record the TOF Value.
Repeat this step for each
Gain Number.
Gain Number
(continued)
A-Class
Displayed Message
*00
<yyy>
- Or, for reflective media:
*00
<yyy>
Sample Calibration Table
Label Value
00 252
01 250
02 248
... ...
31 09
Displayed Message
*01
<yyy>
- Or, for reflective media:
*01
<yyy>
Sample Calibration Table
Label Value
00 252
01 250
02 248
... ...
31 09
GAIN TRAN
(0 - 31)
GAIN REFL
(0 – 31)
TOF Value
248
GAIN TRAN
(0 - 31)
GAIN REFL
(0 – 31)
TOF Value
248
245
234
...
14
Comment
Where 'yyy' represents
the current sensor
reading.
After ENTER is pressed,
an asterisk (*) appears
to denote selection.
Difference Value
Comment
Where 'yyy' represents
the current sensor
reading.
Difference Value
79
