Step Action
Press the MENU Key.
Then, with MEDIA
B
SETTINGS highlighted,
press the ENTER Key.
Using the DOWN Key,
scroll to SENSOR
CALIBRATION then press
C
the ENTER Key. Scroll to
ADVANCED ENTRY and
press the ENTER Key.
Scroll to SENSOR GAIN
D
then press the ENTER Key.
Place the label under the
Sensor Eye Mark and latch
the Head Lift Lever. Using
E
the DOWN Key, scroll to
GAIN TRAN 00 and press
the ENTER Key.
Record the sensor reading
('yyy') as a Label Value in
a table similar to the one
F
shown below, with 32
rows, four columns, and
similar headings.)
Gain Number
(continued)
A-Class
Displayed Message
MEDIA SETTINGS
ADVANCED ENTRY
*00
<yyy>
- Or, for reflective media:
*00
<yyy>
*00
<yyy>
- Or, for reflective media:
*00
<yyy>
Sample Calibration Table
Label Value
00 252
01
02
...
31
SENSOR GAIN
GAIN TRAN
(0 – 31)
GAIN REFL
(0 – 31)
GAIN TRAN
(0 – 31)
GAIN REFL
(0 – 31)
TOF Value
Comment
Press the ESC Key to
abort this procedure.
Press the ESC Key to
abort this procedure.
Press the ESC Key to
abort this procedure.
If using preprinted
•
labels, ensure that
the sampling area is
free of text, graphics,
and perforations.
After ENTER is
•
pressed, an asterisk
(*) appears to denote
selection.
The sensor reading,
where 'yyy' represents
the numeric sample, is
useful in locating the
best sensor position over
the media.
Difference Value
77
