Appendix D
Applicator Interface Overview
The Applicator Interface CCA contains the printer to an applicator interface circuitry; functions and
suggested connections are given below, and in these related sections:
Operational settings; Section 4.2.3.
J3 (COM D) and J4 (COM C) setup; Section 4.2.5.
Testing and diagnostics; Section 4.2.6.
Always wear a wrist strap and follow ESD prevention measures when handling
the Applicator Interface CCA.
Applicator Interface CCA Jumper Configuration
The various ports on the card are configured by arranging hardware jumpers (illustrated below):
A-Class
133
