3. To peel die-cut labels after printing, press down on the Peel Assembly Release Lever to lower
the Peel Assembly; otherwise, proceed directly to Step 6.
4. Remove the labels from 12 inches (30 cm) of the Media Liner. Route the Media Liner down to
the Peel Assembly, over the Latch Roller, and through the Slot as shown below.
Media
A-Class
Peel Assembly
Release Lever
Peel Assembly
Peel Assembly
Slot
Media Liner
Media
Latch Roller
Peel Assembly
19
